Ubiquiti UA-Hub-Door-Mini läbipääsukontroller • 1 uks
€119.04
Not in the Tallinn warehouse right now — shipped from the Baltic warehouse, delivery usually 1–3 working days.
- Ordered before 14:00 from our Tallinn warehouse — dispatched the same business day
- Collection from our Tallinn warehouse is always free — delivery options and prices
- 14-day right of return for private customers
- Need advice? +372 6715042
Product "Ubiquiti UA-Hub-Door-Mini läbipääsukontroller • 1 uks"
Ubiquiti UA-Hub-Door-Mini läbipääsukontroller • 1 uks — The small sibling of UA-Hub-Door: drives one door, without PoE outputs. A cheaper option where the reader is powered elsewhere.
Key Advantages and Features:
- One door: Lock, exit button and door sensor.
- Small body: Fits a tight space.
- UniFi Access: The same management as the larger hub.
- PoE powered: One cable.
Technical Specifications:
| Parameter | Specification |
|---|---|
| Dimensions | 113 x 66 x 27.6 mm, (4.4 x 2.6 x 1.1") |
| Supported Doors | 1 |
| Maximum User Count | 3,000 |
| Input Terminals | (1) Door exit request, (1) Door position |
| Power Method | PoE++, UL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU |
| NDAA Compliant | jah |
| Dry Output Relay | 30V DC, 1A |
| Wet Output Relay | 12V DC, 1A |
| Indoor and Outdoor Use | Indoor only |
| Ambient Operating Temperature | 0 to 40° C, (32 to 104° F) |
| Ambient Operating Humidity | 5 to 90% noncondensing |
| Networking Interface | (3) GbE RJ45 ports |
| PoE Interface | (1) PoE++ input, 50V DC, 1A, (2) PoE+ outputs, 50V DC, 30W per port, (Max 45W aggregated) |
| Max. Power Consumption | 19W (Without PoE output), 50W (With PoE output) |
| LEDs | W/B Learn More |
| Buttons | (1) Factory reset, (1) Dry/Wet switch |
| UA-Lock-Electric (400mA) | 24 AWG length: 25 m (82 ft), 22 AWG length: 42 m (138 ft), 20 AWG length: 66 m (217 ft), 18 UACC-Cable-DoorLockRelay length: 100 m (328 ft) |
| UA-Lock-Magnetic-540kg (500mA) | 24 AWG length: 12 m (39 ft), 22 AWG length: 20 m (66 ft), 20 AWG length: 30 m (98 ft), 18 UACC-Cable-DoorLockRelay length: 46 m (151 ft) |
| UA-Lock-Magnetic-270kg (800mA) | 24 AWG length: 12 m (39 ft), 22 AWG length: 20 m (66 ft), 20 AWG length: 30 m (98 ft), 18 UACC-Cable-DoorLockRelay length: 46 m (151 ft) |
| Other locks (1A) | 24 AWG length: 9 m (30 ft), 22 AWG length: 15 m (49 ft), 20 AWG length: 24 m (79 ft), 18 UACC-Cable-DoorLockRelay length: 36 m (118 ft) |
| CAN/ULC-60839-11-1 Grade | Grade assignment: I |
| Certifications | CE, FCC, IC, UL 294, CAN/ULC-60839-11-1 |
| Document number, and issue date and/or revision level | UA-Hub-Door-Mini, V01 |
Part of the UniFi system. Exact figures are in the manufacturer's table below.
| Access control type: | Controller |
|---|
Ubiquiti – radio links and UniFi networks
Ubiquiti is best known for its wireless products: airMAX and airFiber links take the network where cable cannot go. The UniFi line applies the same logic to wired networking and Wi-Fi.
Why Ubiquiti?
A radio link instead of cable – you can connect two buildings or yards without digging. In surveillance this is often the only sensible way to get a distant camera back to the recorder.
Unified UniFi management – access points, switches and routers in one controller, with a network map and monitoring.
Built for outdoors – most of the radio hardware is designed for a mast or a wall and copes with a Nordic climate.
We stock both point-to-point links and UniFi network gear. With any radio link, remember it needs line of sight — if there is forest or a building in the way, a stronger antenna will not fix it.
